HD-211/SL

Din(Solenoid)Connector,Hidome,10A,250VAC,Socket, 2 Pole + Earthing, Illuminated, PG-11. Available in 24VDC, 48VDC, 110VAC and 230VAC
No. of Poles:	2 Pole + Earth
Reference Standards:	DIN-43650, ISO-4400
Voltage:	24 VDC / 48 VDC / 110 VAC / 230 VAC
Product Weight:	35.00 gms.
Material For Rubber Gasket:	Nitril / Silicon
Material Body:	Polyamide
Insulation Resistance:	100 M Ohms min.
H. V. Breakdown Test:	2KV AC For 1 Minute .
Terminals:	Screw-type
Current Rating:	10 Amps.
Permissible Temp. With/Without Load:	-20 Deg. C to +85 Deg.C
Current Caring Parts:	Brass, Silver Plated .
Contact Resistance:	20 m Ohms max. (Initial)
Colours:	Transparent Body
Gland Size:	PG-11
Mounting:	Screw-type
