| Type: |
Panel Mounting |
| Reference Standards: |
JSS 52710 |
| Permissable Temp.With / Without Load: |
-20 deg. C to + 85 deg. C |
| Terminals: |
Screw Type |
| Mounting: |
Front |
| Panel Thickness: |
2.5 Max. |
| Insulation Resistance(Min): |
1000 M Ohms Min. |
| H. V. Breakdown Test: |
2 KV AC |
| Contact Resistance: |
5 m Ohms Max. |
| Current Rating: |
5 Amps @ 250V AC |
|
|
|
