Switch Type: |
Key removable in 3 Positions |
Permissible Temp For Soldering: |
270 deg. C for 5 sec. max. |
Body: |
Mozak / Engineering Thermoplastic |
Terminal Style: |
Solder-type |
Key Combinations: |
Upto 8 |
Insulation Resistance: |
100 M Ohms |
H. V. Breakdown Test: |
1 KVAC For 1 minute |
Electrical Life: |
10000 Cycles min. |
Current Carrying Parts: |
Terminals-Brass, Silver plated |
Contact Resistance(Max, Initial): |
10 m ohm |
Contact & Voltage Rating: |
0.5 A, 250V AC |
Contact Arrangement: |
SPDT Key Lock Switch |
Permissible Temp For With/Without Load: |
-20 deg. C to + 85 deg. C |
