Finger Proof Safety - Snap Mounting as per IEC-257 & BS-415 |
| Mounting Style: |
Panel Snap Fitting |
| Permissible Temp. With / Without load: |
85 Deg. C |
| Permissible Temp. For Soldering: |
Soldering Time - 5 Sec. At 270 Deg. C. . |
| Panel Thickness(Max): |
2.00 mm |
| Material: |
Polyamide G.F. . |
| Insulation Resistance: |
100 M Ohms |
| H. V. Break Down: |
2 KV/AC For 1 Minute . |
| Current Carrying Parts: |
Brass / Silver / Nickel Plated . |
| Contact Resistance (Initial): |
10 m Ohms |
| Fuse Link Size: |
20 X 5 mm |
| Rated Current / Voltage: |
6.3 Amps @ 250V AC |
