| No. of Poles: |
2P + E, 3P + E |
| Terminals: |
Solder-type |
| Mounting: |
Screw-type |
| Permissible Temp. With/Without Load: |
-20 deg.C to +85 deg. C |
| Approvals: |
VDE (In-process) |
| Voltage: |
250 VAC |
| Material For Rubber Gasket: |
Nitril / Silicon |
| Material Body: |
Polyamide |
| Insulation Resistance: |
100 M Ohms min. |
| H. V. Breakdown Test: |
2 KV AC for 1 Minute |
| Current Rating: |
6 Amps |
| Current Carring Parts Contact: |
Brass, Silver Plated . |
| Contact Resistance: |
20 m Ohms max. (Initial) |
| Colours: |
Black |
| Type: |
Micro Flat Plug |
| Reference Standards: |
DIN-43650, ISO 4400 |
|
|
|
