No. of Poles: |
2 Pole + Earth, 3 pole + Earth |
Terminals: |
Solder-type |
Mounting: |
Screw-type |
Permissible Temp. With/Without Load: |
-20 deg.C to +85 deg. C |
Approvals: |
VDE |
Voltage: |
250V AC |
Product Weight: |
8.50 gms. Approx. |
Material For Rubber Gasket: |
Nitril / Silicon |
Material Body: |
Polyamide |
Insulation Resistance: |
100 M Ohms min. |
H. V. Breakdown Test: |
2 KV AC for 1 Minute |
Current Rating: |
10 Amps. |
Current Carring Parts Contact: |
Brass, Silver Plated . |
Contact Resistance: |
20 m Ohms max. (Initial) |
Colours: |
Black |
Type: |
Flat Plug |
Reference Standards: |
DIN-43650, ISO 4400 |
|
|
|
