Solder / PCB Mountable. Gold / Silver or Tin plated (Polycarbonate / PBTP) |
| Type: |
Printed Circuit Connector With Bellows Contact |
| Temperature(Max): |
80 Deg. C |
| V / A Rating: |
5 Amp. 250Vac |
| Mounting: |
Screw-type |
| Material Contacts: |
Phosphor Bronze, Gold, Silver or Tin Plated |
| Material Body: |
Polycarbonate/PBTP |
| Insulation Resistance(Min): |
1000 M Ohms |
| H. V. Break Down: |
1KV . |
| Contact Resistance, Max(Initial): |
10 m Ohms |
| Card Thickness: |
1.42 mm - 1.8 mm . |
| No. of Contacts: |
6,10,12,16,18, |
| Terminals: |
Solder-type |
|
|
|
|
