| Type: |
PCB Mounting |
| Contact pitch: |
5.00 x 7.62 mm |
| Terminals: |
Brass, Plating Tin |
| Material: |
Body - Polyamide. Spring - Stainless Steel |
| Insulation Resistance(Min): |
1000 M Ohms |
| H. V. Breakdown Test: |
2 KV/AC For 1 Minute |
| Current Rating: |
10 Amps @ 250V AC |
| Wire Size with Protector: |
2.5 sq. mm. max. |
|
|
|
