Type: |
PCB Mounting |
Contact pitch: |
5.00 mm |
Panel Thickness: |
Brass, Plating Tin |
Material: |
Body - Polyamide. Screw - Steel, Zinc Plated |
Insulation Resistance(Min): |
1000 M Ohms |
H. V. Breakdown Test: |
2 KV/AC For 1 Minute |
Current Rating: |
10 Amps @ 250V AC |
Wire Size with Protector: |
2.5 sq. mm. max. |
|
|
|
