C-DOT Approved |
| Type: |
PCB Mounting |
| Contact pitch: |
5.08 mm |
| Terminals: |
Brass, Plating Tin . |
| Product App. Weight(Max): |
2.8 gms |
| Material: |
Polyamide |
| Insulation Resistance(Min): |
1000 M Ohms |
| H. V. Breakdown Test: |
1 KV/AC For 1 Minute . |
| Approvals: |
C-DOT . |
| Current Rating: |
10 Amps, 250V AC |
| Wire Size with Protector: |
2.5 Square mm |
|
|
|
|
