LCSO Approved |
| Type: |
Panel Mounting |
| Test Specification: |
JSS 52710(JAN1994) TYPE TSC - 11 - N . |
| Product App. Weight(Max): |
22 gm . |
| Material: |
Polyamide |
| Insulation Resistance(Min): |
1000 M Ohms |
| H. V. Breakdown Test: |
2 KV/AC For 1 Minute . |
| Current Carrying Parts: |
Terminals: Brass, Nickel Plated . |
| Contact Resistance: |
20 m Ohms |
| Approvals: |
LCSO |
| Current Rating: |
30 Amps, 250V AC |
|
|
|
|
