| Type: |
Panel Mounting |
| Terminals: |
Brass, Nickel Plated |
| Product App. Weight(Max): |
6.3 gm . |
| Material: |
Thermoplastic |
| Insulation Resistance(Min): |
1000 M Ohms |
| H. V. Breakdown Test: |
1.2 KV/AC For 1 Minute |
| Contact Resistance: |
20 m Ohms |
| Current Rating: |
12 Amps @ 250V AC |
|
|
|
