C-DOT, LCSO Approved |
| Type: |
Panel Mounting |
| Terminals: |
Screw-type |
| Mounting: |
Front |
| Panel Thickness: |
3.0 max. |
| Test Specification: |
JSS 52710(1994) TYPE TSC - 10 - N . |
| Product App. Weight(Max): |
12.0 gms |
| Material: |
Polyamide |
| Insulation Resistance(Min): |
1000 M Ohms min. |
| H. V. Breakdown Test: |
2 KVAC for 1 Minute . |
| Current Carrying Parts: |
Terminals: Brass, Nickel Plated. |
| Contact Resistance: |
5 m ohms max. (Initial) |
| Approvals: |
LCSO, CACT, C-DOT . |
| Current Rating: |
15 Amps, 250V AC |
|
|
|
|
