TC-101/E

Type:	Decimal 1 Pole 10 Way Extended PCB
Contact Resistance:	200 m Ohms
Current Rating:	100 mA
Electrical Life:	10000 Cycles
Insulation Resistance(Min):	100 M Ohms
Mechanical Life:	50000 Cycles
Mounting:	Snap In Panel Cutout .
Voltage Rating:	50 VDC
