Elcom » Switches » Key Lock Switches » KLS-5AB

KLS-5AB

KLS-5AB KLS-5AB
Switch Type: Key Removable in 2 Position
Permissible Temp For Soldering: 270 deg. C for 5 sec. max.
Body: Mozak
Terminal Style: Solder-type
Product Weight: 49.5 gm .
Key Combinations: Upto 48
Insulation Resistance: 100 M Ohms at 500 VDC
H. V. Breakdown Test: 1 KVAC For 1 minute .
Electrical Life: 10000 Cycles min.
Current Carrying Parts: Terminals-Copper, Silver plated
Contact Resistance(Max, Initial): 10 m Ohms
Contact & Voltage Rating: 3 A, 250V AC
Contact Arrangement: SPDT Key Lock Switch
Permissible Temp For With/Without Load: -20 deg. C to + 85 deg. C
