Elcom » Switches » Push Button Switches » PBS-1(R)

PBS-1(R)

PBS-1(R) PBS-1(R)
Switch Type: Momentary - Round Head
Permissible Temp For Soldering: 270 deg. C for 5 sec. max.
Permissible Temp For With/Without Load: -20 deg. C to +85 deg. C
Terminal Style: Solder-type
Colours Available For Housing: Bk
Colours Available For Rocker: Rd / Bk / Gn / Yl / Bl / Wh
Product Weight: 4.7 gm .
Mounting: Panel, Screw-type
Mechanical Life: 50,000 Cycles
Material - Terminals: Copper, Silver plated
Contact Arrangement: SPST, Push Button Switch
Contact & Voltage Ratings: 3 A, 250V AC
Contact Resistance(Max Initial): 10 m Ohms
Electrical Life: 10,000 Cycles
H. V. Breakdown Test: 1 KVAC For 1 minute
Insulation Resistance at 500V DC (Min): 100 M Ohms
Material - Body: Nylon
