C-DOT, CE |
| Contact Arrangement: |
NO / NC |
| Permissible Temp For With/Without Load: |
-20 deg. C. to +85 deg. C. |
| Permissible Temp For Soldering: |
270 deg. C. / 5sec. max. |
| Operating Force: |
200 gms. +/-50gms |
| Material: |
Actuator - Polyamide (White). Body - PBT (Black). |
| Terminals: |
Solder -type |
| Insulation Resistance(Min): |
100 M Ohms |
| H. V. Breakdown Test: |
1 KVAC For 1 Minute . |
| Electrical Life: |
10000 Cycles Min. |
| Current Carrying Parts: |
Terminals - Brass, Silver plated |
| Contact Resistance(Max, Initial): |
20 m Ohms |
| Contact & Voltage Rating: |
4 A at 250V AC. |
| Switch Type: |
Momentary SPDT Micro Switch |
| Mechanical Life: |
50,000 Cycles |
